Moving Coil Phono Cartridge ORTOFON SPU A Wood
Regular price €1.889,00VAT included in price for European Union countries. VAT may be adjusted based on delivery country at check-out. Shipping cost (free above 99€ purchase within European Union) will be added at check-out.
A perfect combination of Japanese and Danish craftsmanship and technique, the SPU Wood A is beautiful in finish and form, as well as in its sonic expression
The SPU Wood A unique characteristics includes an outstanding housing made of Japanese Beech wood, famous for its strength and hardness. For the exclusive surface treatment, the 6000 years old Japanese Urushi lacquer method was chosen in order to achieve a hard, resistant and beautiful multilayer surface in dark maroon colour.
The wooden housing has a strong influence resulting in a very pleasant, open, dynamic, straightforward and present tone range characteristic for the SPU sound.
- Output voltage at 1000 Hz, 5cm/sec. - 0.18 mV
- Channel balance at 1 kHz - 1.5 dB
- Channel separation at 1 kHz - 20 dB
- Channel separation at 15 kHz - 10 dB
- Frequency response - 20-25.000 Hz ±2 dB
- Tracking ability at 315Hz at recommended tracking force *) - 70 µm
- Compliance, dynamic, lateral - 10 µm/mN
- Stylus type - Spherical
- Stylus tip radius - R 18 µm
- Tracking force range - 3.0-5.0 g (30-50 mN)
- Tracking force, recommended - 4.0 g (40 mN)
- Tracking angle - 20°
- Internal impedance, DC resistance - 2.5 ohm
- Recommended load impedance > 10 ohm
- Cartridge body material - Wood
- Cartridge color - Dark maroon
- Cartridge weight - 29 g
*) Typical value
